ANAN-G2-1K 1000W+ HF & 6M SDR Transceiver

$7495

Pre-Order

Please note we will ship new orders once the backlog of preorders have been shipped out, you may place your preorder (lead time 12-16 weeks).

G2-1K delivers the performance of a high-end SDR and a 1000W+ amplifier in one tightly integrated platform, with superior protection, simplified operation, and optimized signal-chain performance compared with a conventional 100W transceiver plus external amplifier setup.

True one-box high-power solution
No separate transceiver, no separate amplifier, no extra interconnects to manage.

Optimized exciter-to-amplifier chain
The SDR and 1 kW PA are designed to work together, so there is no guesswork in drive levels or interface behavior.

Better protection
The radio can monitor temperature, current, SWR, reflected power, and drive conditions as one complete system and react immediately.

Reduced cabling and clutter
No need for extra RF jumpers, ALC lines, CAT control, or amplifier keying cables.

More professional platform
It feels and behaves like one purpose-built high-power SDR rather than two separate products patched together.

Feature	G2-1K Integrated 1000W+ SDR	100 W Transceiver + External Amp
System design	Single integrated platform	Two separate devices that must work together
Setup	Simple, one-box operation	More cables, more setup, more points of failure
Drive matching	Optimized internally	Risk of underdrive or overdrive
Band switching	Automatic and coordinated	Requires CAT/band data/manual coordination
T/R sequencing	Designed as one system	Depends on inter-device timing
Protection	Centralized, fast, coordinated	Radio and amp protect themselves separately
Signal cleanliness	Better potential for optimized linearity	Depends heavily on setup and interface
Predistortion integration	Easier and more consistent	Often harder across separate equipment
Cabling	Minimal	RF, PTT, ALC, CAT, band data, grounding
Ease of use	Very straightforward	More complex to operate correctly
Reliability in operation	Fewer operator errors	More chance of switching/drive mistakes
Field/commercial deployment	Excellent	Less convenient and less elegant

Technical Specifications

General Specifications:

Architecture: Direct Sampling DDC/DUC Transceiver
Microprecessor controlled protection for SWR, Temperature, Voltage/Current (Over or Under)
Interface: Ethernet
Phase Noise (Clock): -149dB @ 10Khz
TCXO Stability (Typical): /- .1 PPM
Modes: CW, SSB, NFM, AM, Digital
Antenna Ports: Three SO-239 50 ohms Software Configurable Ports, One BNC for RX2
Frequency Resolution: 1 Hz

Electrical Specifications:
