ANAN-G2-1K 1000W+ HF & 6M SDR Transceiver

$7495 $5795

Pre-Order

Technical Sheet

We have 25 slots available in the First production Lot, pricing will revert to $7495 after these slots have been taken.

True one-box high-power solution
No separate transceiver, no separate amplifier, no extra interconnects to manage.

Optimized exciter-to-amplifier chain
The SDR and 1 kW PA are designed to work together, so there is no guesswork in drive levels or interface behavior.

Better protection
The radio can monitor temperature, current, SWR, reflected power, and drive conditions as one complete system and react immediately.

Reduced cabling and clutter
No need for extra RF jumpers, ALC lines, CAT control, or amplifier keying cables.

More professional platform
It feels and behaves like one purpose-built high-power SDR rather than two separate products patched together.

Feature	G2-1K Integrated 1000W+ SDR	100 W Transceiver + External Amp
System design	Single integrated platform	Two separate devices that must work together
Setup	Simple, one-box operation	More cables, more setup, more points of failure
Drive matching	Optimized internally	Risk of underdrive or overdrive
Band switching	Automatic and coordinated	Requires CAT/band data/manual coordination
T/R sequencing	Designed as one system	Depends on inter-device timing
Protection	Centralized, fast, coordinated	Radio and amp protect themselves separately
Signal cleanliness	Better potential for optimized linearity	Depends heavily on setup and interface
Predistortion integration	Easier and more consistent	Often harder across separate equipment
Cabling	Minimal	RF, PTT, ALC, CAT, band data, grounding
Ease of use	Very straightforward	More complex to operate correctly
Reliability in operation	Fewer operator errors	More chance of switching/drive mistakes
Field/commercial deployment	Excellent	Less convenient and less elegant

Technical Specifications

General Specifications:

Architecture: Direct Sampling DDC/DUC Transceiver
Microprecessor controlled protection for SWR, Temperature, Voltage/Current (Over or Under)
Interface: Ethernet
Phase Noise (Clock): -149dB @ 10Khz
TCXO Stability (Typical): /- .1 PPM
Modes: CW, SSB, NFM, AM, Digital
Antenna Port: SO-239
Frequency Resolution: 1 Hz

Electrical Specifications:

48-53.5v DC 40A

Mechanical Specifications:

15Kg (approx. Weight)
49.7cm L x 38.4cm W x 13.8cm H (not including extrusions)

Receiver Specifications:

Receiver Architecture: Direct Down Conversion
Dual 16 bit Phase Synchronous ADCs
Independent filter banks for each ADC
10/6M LNAs
Frequency Coverage: 9Khz to 60Mhz
Attenuator: 1-30dB step attenuator
Reciprocal Mixing Dynamic Range (RMDR): 116dB @ 2Khz
Receiver Phase noise: -149dB @ 10Khz
Image rejection: 100dB
Hardware support for 7 independent receivers assignable to either ADC

Transmitter Specifications:

Transmitter Architecture: Direct Up Conversion
DAC Resolution: 16 bit
RF Output Power (Maximum): 1000W PEP: SSB/CW. 500W: FM, RTTY, Digital. 275W: AM, 6M 400W SSB/CW and FM, RTTY, Digital 200W.
IMD: IMD3 typically -62dB @ 1000W PEP output on 20M
Harmonics: Typically better than -50dBc on HF and -60dBc on 6M
Carrier and Opposite Sideband Suppression: Better than -80dBc
Transverter IF Output: 0db to 15dB

IOs:
